Operating Voltage

24VDC±10%(1)

Installation Method

DIN rail installation(1)

Current consumption of a single controller

Under 100mA(When connecting the sensor)(1)

Number of connected sensors

Two pairs of sensors(1)

The communication with sensors

RS485(1)

Number of controllers connected in parallel

Up to 16 controllers can be connected(1)

Display

240*240TFT display(1)

Indicator light

Output 1~3 and function indicator light red(1)

Analog Output

Analog output current 4~20mA, voltage 0~5V can be switched(1)

Switching output

3-channel output, NO, NC, PO, PC can be switched(1)

External input

3-channel input, NPN and PNP input optional(1)

Display resolution

1μm(1)

Display range

-99.999mm~99.999mm(1)

Protective structure

IP40(1)

Operating temperature

10℃~+50℃(1)

Working Humidity

35%RH~85%RH(1)

Insulation Resistance

The resistance of all connecting terminals and shells is above 20MΩ(1)

Withstand Voltage

All connection terminals and housing withstand voltage AC 1000V(1)

Vibration Resistance

Frequency 10~55HZ, 1.5m double amplitude, two hours each in X, Y and Y directions(1)

Shock proof

98m/s 2 (about 10G) 5 times each in X, Y, and Z directions(1)
